LQM2HPN2R2MEHL
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2UH 1.3A 188 MOHM
- CategoryFixed Inductors
- Datasheet LQM2HPN2R2MEHL Datasheet
-
ECAD Model
- Share
In Stock: 1,134
Can ship immediately
Pricing:
- 1$0.47
- 3,000$0.17702
- 6,000$0.16661
- 15,000$0.16141
- 30,000$0.1562
Quote It
Technical Details
- Series:LQM2
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Multilayer
- Material - Core:Ferrite
- Inductance:2.2 µH
- Tolerance:±20%
- Current Rating (Amps):1.3 A
- Current - Saturation (Isat):800mA
- Shielding:Shielded
- DC Resistance (DCR):188mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:30MHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1008 (2520 Metric)
- Supplier Device Package:1008 (2520 Metric)
- Size / Dimension:0.098" L x 0.079" W (2.50mm x 2.00mm)
- Height - Seated (Max):0.031" (0.80mm)
