SRN6028-150M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 15UH 1.8A 114 MOHM SMD
- CategoryFixed Inductors
- Datasheet SRN6028-150M Datasheet
-
ECAD Model
- Share
In Stock: 1,097
Can ship immediately
Pricing:
- 1$0.46
- 1,000$0.15895
- 3,000$0.1496
- 5,000$0.1463
Quote It
Technical Details
- Series:SRN6028
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:15 µH
- Tolerance:±20%
- Current Rating (Amps):1.8 A
- Current - Saturation (Isat):1.6A
- Shielding:Semi-Shielded
- DC Resistance (DCR):114mOhm Max
- Q @ Freq:14 @ 2.52MHz
- Frequency - Self Resonant:17MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.236" L x 0.236" W (6.00mm x 6.00mm)
- Height - Seated (Max):0.110" (2.80mm)
