CPL2508T220M
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 180MA 3.12 OHM
- CategoryFixed Inductors
- Datasheet CPL2508T220M Datasheet
-
ECAD Model
- Share
In Stock: 523
Can ship immediately
Pricing:
- 1$0.47
Quote It
Technical Details
- Series:CPL
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):180 mA
- Current - Saturation (Isat):180mA
- Shielding:Shielded
- DC Resistance (DCR):3.12Ohm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:-
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.098" L x 0.059" W (2.50mm x 1.50mm)
- Height - Seated (Max):0.031" (0.80mm)
