SRP2010-R68M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 680NH 3.1A 49 MOHM SMD
- CategoryFixed Inductors
- Datasheet SRP2010-R68M Datasheet
-
ECAD Model
- Share
In Stock: 335
Can ship immediately
Pricing:
- 1$0.48
- 3,000$0.1632
- 6,000$0.1596
Quote It
Technical Details
- Series:SRP2010
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Iron Powder
- Inductance:680 nH
- Tolerance:±20%
- Current Rating (Amps):3.1 A
- Current - Saturation (Isat):3.7A
- Shielding:Shielded
- DC Resistance (DCR):49mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0806 (2016 Metric)
- Supplier Device Package:0806 (2016 Metric)
- Size / Dimension:0.079" L x 0.063" W (2.00mm x 1.60mm)
- Height - Seated (Max):0.037" (0.95mm)
