VLS6045AF-8R2M

Technical Details

• Series:VLS
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:8.2 µH
• Tolerance:±20%
• Current Rating (Amps):3.7 A
• Current - Saturation (Isat):3.2A
• Shielding:Shielded
• DC Resistance (DCR):42mOhm

• Q @ Freq:-
• Frequency - Self Resonant:-
• Ratings:-
• Operating Temperature:-40°C ~ 105°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.236" L x 0.236" W (6.00mm x 6.00mm)
• Height - Seated (Max):0.177" (4.50mm)
