SRN5040TA-6R8M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 6.8UH 2.5A 43 MOHM SMD
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 833
Can ship immediately
Pricing:
- 1$0.55
Quote It
Technical Details
- Series:SRN5040TA
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:6.8 µH
- Tolerance:±20%
- Current Rating (Amps):2.5 A
- Current - Saturation (Isat):3.3A
- Shielding:Semi-Shielded
- DC Resistance (DCR):43mOhm
- Q @ Freq:15 @ 100kHz
- Frequency - Self Resonant:32MHz
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.195" L x 0.195" W (4.95mm x 4.95mm)
- Height - Seated (Max):0.161" (4.10mm)
