LQH5BPH330MT0L
TOKO / Murata- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 33UH 750MA 516 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 569
Can ship immediately
Pricing:
- 1$0.62
Quote It
Technical Details
- Series:LQH5
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:33 µH
- Tolerance:±20%
- Current Rating (Amps):750 mA
- Current - Saturation (Isat):1A
- Shielding:Shielded
- DC Resistance (DCR):516mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:6MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.197" L x 0.197" W (5.00mm x 5.00mm)
- Height - Seated (Max):0.087" (2.20mm)
