SDR0604-561KL
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 560UH 180MA 4 OHM SMD
- CategoryFixed Inductors
- Datasheet SDR0604-561KL Datasheet
-
ECAD Model
- Share
In Stock: 320
Can ship immediately
Pricing:
- 1$0.57
- 1,200$0.2275
Quote It
Technical Details
- Series:SDR0604
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:560 µH
- Tolerance:±10%
- Current Rating (Amps):180 mA
- Current - Saturation (Isat):260mA
- Shielding:Unshielded
- DC Resistance (DCR):4Ohm Max
- Q @ Freq:24 @ 252kHz
- Frequency - Self Resonant:3MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.228" L x 0.228" W (5.80mm x 5.80mm)
- Height - Seated (Max):0.189" (4.80mm)
