VLS201612HBX-R47M-1
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 470NH 3.2A 42 MOHM SMD
- CategoryFixed Inductors
- Datasheet VLS201612HBX-R47M-1 Datasheet
-
ECAD Model
- Share
In Stock: 235
Can ship immediately
Pricing:
- 1$0.61
- 2,000$0.25806
- 4,000$0.24288
- 6,000$0.23529
- 10,000$0.2277
Quote It
Technical Details
- Series:VLS-HBX-1
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Metal
- Inductance:470 nH
- Tolerance:±20%
- Current Rating (Amps):3.2 A
- Current - Saturation (Isat):3.78A
- Shielding:Shielded
- DC Resistance (DCR):42mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0806 (2016 Metric)
- Supplier Device Package:0806 (2016 Metric)
- Size / Dimension:0.079" L x 0.063" W (2.00mm x 1.60mm)
- Height - Seated (Max):0.047" (1.20mm)
