B82498F3681J000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 680NH 190MA 1.7 OHM
- CategoryFixed Inductors
- Datasheet B82498F3681J000 Datasheet
-
ECAD Model
- Share
In Stock: 593
Can ship immediately
Pricing:
- 1$0.74
- 3,000$0.3054
- 6,000$0.29586
- 15,000$0.28631
- 30,000$0.27677
Quote It
Technical Details
- Series:SIMID
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ceramic
- Inductance:680 nH
- Tolerance:±5%
- Current Rating (Amps):190 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):1.7Ohm Max
- Q @ Freq:23 @ 50MHz
- Frequency - Self Resonant:300MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:25 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:0805 (2012 Metric)
- Size / Dimension:0.091" L x 0.067" W (2.30mm x 1.70mm)
- Height - Seated (Max):0.055" (1.40mm)
