ASPI-0315S-220M-T
Abracon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 400MA 430 MOHM
- CategoryFixed Inductors
- Datasheet ASPI-0315S-220M-T Datasheet
-
ECAD Model
- Share
In Stock: 688
Can ship immediately
Pricing:
- 1$0.76
- 2,000$0.323
- 4,000$0.304
- 6,000$0.2945
- 10,000$0.285
Quote It
Technical Details
- Series:ASPI-0315S
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):400 mA
- Current - Saturation (Isat):-
- Shielding:Shielded
- DC Resistance (DCR):430mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.146" L x 0.146" W (3.70mm x 3.70mm)
- Height - Seated (Max):0.071" (1.80mm)
