B82144B2272K000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.7UH 3.55A 60 MOHM TH
- CategoryFixed Inductors
- Datasheet B82144B2272K000 Datasheet
-
ECAD Model
- Share
In Stock: 1,104
Can ship immediately
Pricing:
- 1$0.78
- 1,000$0.33065
- 3,000$0.3112
- 5,000$0.30148
- 10,000$0.29175
- 25,000$0.28203
Quote It
Technical Details
- Series:LBC
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:2.7 µH
- Tolerance:±10%
- Current Rating (Amps):3.55 A
- Current - Saturation (Isat):5.4A
- Shielding:Unshielded
- DC Resistance (DCR):60mOhm Max
- Q @ Freq:60 @ 2.52MHz
- Frequency - Self Resonant:120MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical Cylinder
- Supplier Device Package:-
- Size / Dimension:0.256" Dia (6.50mm)
- Height - Seated (Max):0.551" (14.00mm)
