744045003
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 3.3UH 1.4A 130 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 326
Can ship immediately
Pricing:
- 1$0.8
- 500$0.51
Quote It
Technical Details
- Series:WE-LQ
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:3.3 µH
- Tolerance:±20%
- Current Rating (Amps):1.4 A
- Current - Saturation (Isat):2.7A
- Shielding:Unshielded
- DC Resistance (DCR):130mOhm Max
- Q @ Freq:45 @ 1MHz
- Frequency - Self Resonant:58MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1812 (4532 Metric)
- Supplier Device Package:1812
- Size / Dimension:0.177" L x 0.126" W (4.50mm x 3.20mm)
- Height - Seated (Max):0.114" (2.90mm)
