SRR7045-471M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 470UH 320MA 1.1OHM SMD
- CategoryFixed Inductors
- Datasheet SRR7045-471M Datasheet
-
ECAD Model
- Share
In Stock: 670
Can ship immediately
Pricing:
- 1$0.84
- 1,000$0.27455
- 3,000$0.2584
- 5,000$0.2527
Quote It
Technical Details
- Series:SRR7045
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:470 µH
- Tolerance:±20%
- Current Rating (Amps):320 mA
- Current - Saturation (Isat):220mA
- Shielding:Shielded
- DC Resistance (DCR):1.1Ohm Max
- Q @ Freq:80 @ 796kHz
- Frequency - Self Resonant:3MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.276" L x 0.276" W (7.00mm x 7.00mm)
- Height - Seated (Max):0.189" (4.80mm)
