VLCF4028T-150MR88-2
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 15UH 880MA 170 MOHM
- CategoryFixed Inductors
- Datasheet VLCF4028T-150MR88-2 Datasheet
-
ECAD Model
- Share
In Stock: 543
Can ship immediately
Pricing:
- 1$0.84
- 500$0.441
- 1,000$0.357
- 2,500$0.336
- 5,000$0.3255
- 12,500$0.315
- 25,000$0.3045
Quote It
Technical Details
- Series:VLCF
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:15 µH
- Tolerance:±20%
- Current Rating (Amps):880 mA
- Current - Saturation (Isat):880mA
- Shielding:Shielded
- DC Resistance (DCR):170mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.157" L x 0.157" W (4.00mm x 4.00mm)
- Height - Seated (Max):0.110" (2.80mm)
