PF0560.473NLT
PulseLarsen Antenna
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 47UH 1.9A 128 MOHM SMD
- CategoryFixed Inductors
- Datasheet PF0560.473NLT Datasheet
-
ECAD Model
- Share
In Stock: 1,319
Can ship immediately
Pricing:
- 1$1.64
- 620$0.792
- 1,240$0.704
- 3,100$0.682
- 6,200$0.66
- 15,500$0.638
Quote It
Technical Details
- Series:PF0560NL
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:47 µH
- Tolerance:±25%
- Current Rating (Amps):1.9 A
- Current - Saturation (Isat):2.1A
- Shielding:Shielded
- DC Resistance (DCR):128mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:10MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.409" L x 0.406" W (10.40mm x 10.30mm)
- Height - Seated (Max):0.157" (4.00mm)
