SDR1006-390KL
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 39UH 1.35A 140MOHM SMD
- CategoryFixed Inductors
- Datasheet SDR1006-390KL Datasheet
-
ECAD Model
- Share
In Stock: 554
Can ship immediately
Pricing:
- 1$0.88
- 800$0.306
- 1,600$0.289
- 4,000$0.272
- 5,600$0.266
Quote It
Technical Details
- Series:SDR1006
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:39 µH
- Tolerance:±10%
- Current Rating (Amps):1.35 A
- Current - Saturation (Isat):2.6A
- Shielding:Unshielded
- DC Resistance (DCR):140mOhm Max
- Q @ Freq:20 @ 2.52MHz
- Frequency - Self Resonant:9MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.386" L x 0.386" W (9.80mm x 9.80mm)
- Height - Seated (Max):0.228" (5.80mm)
