P0770.152NL
PulseLarsen Antenna
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1.5UH 2.6A 50 MOHM SMD
- CategoryFixed Inductors
- Datasheet P0770.152NL Datasheet
-
ECAD Model
- Share
In Stock: 185
Can ship immediately
Pricing:
- 1$0.88
- 10$0.81253
- 145$0.59158
- 580$0.45711
- 1,015$0.40822
- 2,610$0.396
Quote It
Technical Details
- Series:P0770NL
- Package:Tray
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:1.5 µH
- Tolerance:±20%
- Current Rating (Amps):2.6 A
- Current - Saturation (Isat):2.6A
- Shielding:Unshielded
- DC Resistance (DCR):50mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 130°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.260" L x 0.175" W (6.60mm x 4.45mm)
- Height - Seated (Max):0.115" (2.92mm)
