1217AS-H-2R2N=P3
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2UH 8.7A 9.9 MOHM
- CategoryFixed Inductors
- Datasheet 1217AS-H-2R2N=P3 Datasheet
-
ECAD Model
- Share
In Stock: 632
Can ship immediately
Pricing:
- 1$0.94
- 1,000$0.39772
- 3,000$0.37433
- 5,000$0.36263
- 10,000$0.35093
- 25,000$0.33924
Quote It
Technical Details
- Series:DEM8045C
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:2.2 µH
- Tolerance:±30%
- Current Rating (Amps):8.7 A
- Current - Saturation (Isat):9.3A
- Shielding:Shielded
- DC Resistance (DCR):9.9mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.315" L x 0.315" W (8.00mm x 8.00mm)
- Height - Seated (Max):0.177" (4.50mm)
