CR75NP-101KC
Sumida Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 100UH 720MA 430 MOHM
- CategoryFixed Inductors
- Datasheet CR75NP-101KC Datasheet
-
ECAD Model
- Share
In Stock: 263
Can ship immediately
Pricing:
- 1$0.91
- 1,000$0.416
- 3,000$0.403
- 5,000$0.39
- 10,000$0.377
- 25,000$0.364
Quote It
Technical Details
- Series:CR75
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:100 µH
- Tolerance:±10%
- Current Rating (Amps):720 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):430mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:9.2MHz
- Ratings:-
- Operating Temperature:-40°C ~ 100°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.307" L x 0.276" W (7.80mm x 7.00mm)
- Height - Seated (Max):0.217" (5.50mm)
