SRR3818A-101M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 100UH 340MA 2.6OHM SMD
- CategoryFixed Inductors
- Datasheet SRR3818A-101M Datasheet
-
ECAD Model
- Share
In Stock: 697
Can ship immediately
Pricing:
- 1$0.92
Quote It
Technical Details
- Series:SRR3818A
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:100 µH
- Tolerance:±20%
- Current Rating (Amps):340 mA
- Current - Saturation (Isat):200mA
- Shielding:Shielded
- DC Resistance (DCR):2.6Ohm Max
- Q @ Freq:-
- Frequency - Self Resonant:11MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.150" L x 0.150" W (3.80mm x 3.80mm)
- Height - Seated (Max):0.079" (2.00mm)
