SRR0745A-561M

J.W. Miller / Bourns
In Stock: 2,666

Can ship immediately

Pricing:
  • 1$1.02
  • 10$0.94786
  • 100$0.68576
  • 500$0.52528

Quote It

Technical Details

  • Series:SRR0745A
  • Package:Tape & Reel (TR)Cut Tape (CT)
  • Part Status:Active
  • Type:-
  • Material - Core:Ferrite
  • Inductance:560 µH
  • Tolerance:±20%
  • Current Rating (Amps):260 mA
  • Current - Saturation (Isat):300mA
  • Shielding:Shielded
  • DC Resistance (DCR):2.6Ohm Max



  • Q @ Freq:-
  • Frequency - Self Resonant:-
  • Ratings:AEC-Q200
  • Operating Temperature:-40°C ~ 125°C
  • Inductance Frequency - Test:1 kHz
  • Features:-
  • Mounting Type:Surface Mount
  • Package / Case:Nonstandard
  • Supplier Device Package:-
  • Size / Dimension:0.287" L x 0.287" W (7.30mm x 7.30mm)
  • Height - Seated (Max):0.185" (4.70mm)

Related Products


SRR3818A-150M

FIXED IND 15UH 1.05A 340MOHM SMD

SRR3818A-150M Datasheet
  • 1: $0.92000

DR73-101-R

FIXED IND 100UH 730MA 527 MOHM

DR73-101-R Datasheet
  • 1: $0.92000
  • 1350: $ 0.44800
  • 2700: $0.43400

SRR0745A-121M

FIXED IND 120UH 600MA 550MOHM SM

SRR0745A-121M Datasheet
  • 1: $1.02000
  • 1000: $0.38450
  • 3000: $0.36188

DR73-150-R

FIXED IND 15UH 1.83A 84.4 MOHM

DR73-150-R Datasheet
  • 1: $0.92000
  • 1350: $ 0.44800
  • 2700: $0.43400

DRA124-151-R

FIXED IND 150UH 967MA 454 MOHM

DRA124-151-R Datasheet
  • 1: $1.02000
  • 750: $1.02000

SRR4528A-121M

FIXED IND 120UH 530MA 0.7OHM SMD

SRR4528A-121M Datasheet
  • 1: $1.02000

SRR4528A-1R8Y

FIXED IND 1.8UH 4.2A 0.2 OHM SMD

SRR4528A-1R8Y Datasheet
  • 1: $1.02000

SRR4528A-2R7Y

FIXED IND 2.7UH 3.4A .29OHM SMD

SRR4528A-2R7Y Datasheet
  • 1: $1.02000

SRR4528A-391M

FIXED IND 390UH 280MA 2.38 OHM

SRR4528A-391M Datasheet
  • 1: $1.02000

SRR0745A-821M
