ASPI-8040S-180M-T
Abracon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 18UH 2.4A 53 MOHM SMD
- CategoryFixed Inductors
- Datasheet ASPI-8040S-180M-T Datasheet
-
ECAD Model
- Share
In Stock: 460
Can ship immediately
Pricing:
- 1$0.92
- 1,000$0.3315
- 3,000$0.312
- 5,000$0.30225
- 10,000$0.2925
- 25,000$0.28275
Quote It
Technical Details
- Series:ASPI-8040S
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:18 µH
- Tolerance:±20%
- Current Rating (Amps):2.4 A
- Current - Saturation (Isat):2.7A
- Shielding:Shielded
- DC Resistance (DCR):53mOhm
- Q @ Freq:-
- Frequency - Self Resonant:11MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.315" L x 0.315" W (8.00mm x 8.00mm)
- Height - Seated (Max):0.165" (4.20mm)
