SRR4828A-2R7Y
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.7UH 4A 34 MOHM SMD
- CategoryFixed Inductors
- Datasheet SRR4828A-2R7Y Datasheet
-
ECAD Model
- Share
In Stock: 366
Can ship immediately
Pricing:
- 1$0.92
Quote It
Technical Details
- Series:SRR4828A
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:2.7 µH
- Tolerance:±30%
- Current Rating (Amps):4 A
- Current - Saturation (Isat):2.2A
- Shielding:Shielded
- DC Resistance (DCR):34mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:80MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.189" L x 0.189" W (4.80mm x 4.80mm)
- Height - Seated (Max):0.118" (3.00mm)
