IMC1812ER5R6K
Vishay / Dale
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 5.6UH 300MA 1.1 OHM
- CategoryFixed Inductors
- Datasheet IMC1812ER5R6K Datasheet
-
ECAD Model
- Share
In Stock: 304
Can ship immediately
Pricing:
- 1$1.27
- 1,000$0.448
- 2,500$0.434
- 5,000$0.42
- 12,500$0.406
- 25,000$0.392
Quote It
Technical Details
- Series:IMC-1812
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Iron Powder
- Inductance:5.6 µH
- Tolerance:±10%
- Current Rating (Amps):300 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):1.1Ohm Max
- Q @ Freq:50 @ 7.96MHz
- Frequency - Self Resonant:33MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:7.96 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1812 (4532 Metric)
- Supplier Device Package:1812
- Size / Dimension:0.177" L x 0.126" W (4.50mm x 3.20mm)
- Height - Seated (Max):0.134" (3.40mm)
