SRU1063A-150Y
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 15UH 3.2A 42 MOHM SMD
- CategoryFixed Inductors
- Datasheet SRU1063A-150Y Datasheet
-
ECAD Model
- Share
In Stock: 331
Can ship immediately
Pricing:
- 1$1.28
- 500$0.4743
- 1,000$0.4216
- 2,500$0.4123
Quote It
Technical Details
- Series:SRU1063A
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:15 µH
- Tolerance:±30%
- Current Rating (Amps):3.2 A
- Current - Saturation (Isat):3.4A
- Shielding:Shielded
- DC Resistance (DCR):42mOhm Max
- Q @ Freq:12 @ 2.52MHz
- Frequency - Self Resonant:14MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:4-SMD
- Supplier Device Package:-
- Size / Dimension:0.394" L x 0.394" W (10.00mm x 10.00mm)
- Height - Seated (Max):0.268" (6.80mm)
