SRP7030-R20M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 200NH 24A 3 MOHM SMD
- CategoryFixed Inductors
- Datasheet SRP7030-R20M Datasheet
-
ECAD Model
- Share
In Stock: 246
Can ship immediately
Pricing:
- 1$1.3
- 1,000$0.5032
- 3,000$0.4921
Quote It
Technical Details
- Series:SRP7030
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Iron
- Inductance:200 nH
- Tolerance:±20%
- Current Rating (Amps):24 A
- Current - Saturation (Isat):36A
- Shielding:Shielded
- DC Resistance (DCR):3mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.307" L x 0.276" W (7.80mm x 7.00mm)
- Height - Seated (Max):0.126" (3.20mm)
