UP1B-220-R
PowerStor (Eaton)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 1A 254.1 MOHM SMD
- CategoryFixed Inductors
- Datasheet UP1B-220-R Datasheet
-
ECAD Model
- Share
In Stock: 720
Can ship immediately
Pricing:
- 1$1.43
- 900$0.6783
- 1,800$0.6384
- 2,700$0.61845
- 6,300$0.5985
Quote It
Technical Details
- Series:UNI-PAC™
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):1 A
- Current - Saturation (Isat):1.2A
- Shielding:Unshielded
- DC Resistance (DCR):254.1mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.350" L x 0.240" W (8.89mm x 6.10mm)
- Height - Seated (Max):0.197" (5.00mm)
