IHLP4040DZER4R7M01
Vishay / Dale
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 4.7UH 9.5A 16.5 MOHM
- CategoryFixed Inductors
- Datasheet IHLP4040DZER4R7M01 Datasheet
-
ECAD Model
- Share
In Stock: 101
Can ship immediately
Pricing:
- 1$1.44
- 500$1.156
- 1,000$1.054
- 2,500$1.02
- 5,000$0.986
Quote It
Technical Details
- Series:IHLP-4040DZ-01
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Molded
- Material - Core:-
- Inductance:4.7 µH
- Tolerance:±20%
- Current Rating (Amps):9.5 A
- Current - Saturation (Isat):17A
- Shielding:Shielded
- DC Resistance (DCR):16.5mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:4040
- Size / Dimension:0.425" L x 0.400" W (10.80mm x 10.16mm)
- Height - Seated (Max):0.157" (4.00mm)
