B82462A4153K000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 15UH 900MA 210 MOHM
- CategoryFixed Inductors
- Datasheet B82462A4153K000 Datasheet
-
ECAD Model
- Share
In Stock: 858
Can ship immediately
Pricing:
- 1$1.47
- 2,500$0.46624
Quote It
Technical Details
- Series:B82462-A4
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:15 µH
- Tolerance:±10%
- Current Rating (Amps):900 mA
- Current - Saturation (Isat):1.5A
- Shielding:Unshielded
- DC Resistance (DCR):210mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.236" L x 0.236" W (6.00mm x 6.00mm)
- Height - Seated (Max):0.118" (3.00mm)
