B82442A1682K000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 6.8UH 810MA 120 MOHM
- CategoryFixed Inductors
- Datasheet B82442A1682K000 Datasheet
-
ECAD Model
- Share
In Stock: 608
Can ship immediately
Pricing:
- 1$1.66
- 1,500$0.71546
- 3,000$0.6931
- 7,500$0.67074
- 10,500$0.64839
Quote It
Technical Details
- Series:SIMID
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Last Time Buy
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:6.8 µH
- Tolerance:±10%
- Current Rating (Amps):810 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):120mOhm Max
- Q @ Freq:10 @ 7.96MHz
- Frequency - Self Resonant:24MHz
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:7.96 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:2-SMD, J-Lead
- Supplier Device Package:2220 (5650 Metric)
- Size / Dimension:0.220" L x 0.197" W (5.60mm x 5.00mm)
- Height - Seated (Max):0.209" (5.30mm)
