744062180
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 18UH 1.28A 100 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 427
Can ship immediately
Pricing:
- 1$1.57
- 500$1.18
Quote It
Technical Details
- Series:WE-TPC
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:18 µH
- Tolerance:±30%
- Current Rating (Amps):1.28 A
- Current - Saturation (Isat):1A
- Shielding:Shielded
- DC Resistance (DCR):100mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:25MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:2727 (6868 Metric)
- Supplier Device Package:-
- Size / Dimension:0.268" L x 0.268" W (6.80mm x 6.80mm)
- Height - Seated (Max):0.098" (2.50mm)
