MDH7045C-221MA=P3
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 220UH 510MA 550 MOHM
- CategoryFixed Inductors
- Datasheet MDH7045C-221MA=P3 Datasheet
-
ECAD Model
- Share
In Stock: 853
Can ship immediately
Pricing:
- 1$1.73
Quote It
Technical Details
- Series:MDH7045C
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Not For New Designs
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:220 µH
- Tolerance:±20%
- Current Rating (Amps):510 mA
- Current - Saturation (Isat):530mA
- Shielding:Unshielded
- DC Resistance (DCR):550mOhm
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.291" L x 0.276" W (7.40mm x 7.00mm)
- Height - Seated (Max):0.189" (4.80mm)
