PF0464.223NLT
PulseLarsen Antenna
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 1.2A 113 MOHM SMD
- CategoryFixed Inductors
- Datasheet PF0464.223NLT Datasheet
-
ECAD Model
- Share
In Stock: 514
Can ship immediately
Pricing:
- 1$1.58
- 1,200$0.672
- 3,600$0.651
- 6,000$0.63
- 12,000$0.609
Quote It
Technical Details
- Series:PF0464NL
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:-
- Material - Core:-
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):1.2 A
- Current - Saturation (Isat):1.2A
- Shielding:Shielded
- DC Resistance (DCR):113mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:21MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.283" L x 0.283" W (7.20mm x 7.20mm)
- Height - Seated (Max):0.118" (3.00mm)
