ASPI-1306S-151M-T
Abracon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 150UH 1.3A 293 MOHM
- CategoryFixed Inductors
- Datasheet ASPI-1306S-151M-T Datasheet
-
ECAD Model
- Share
In Stock: 310
Can ship immediately
Pricing:
- 1$1.58
- 250$0.987
- 500$0.846
- 750$0.799
- 1,250$0.752
- 2,500$0.7285
- 6,250$0.705
- 12,500$0.6815
Quote It
Technical Details
- Series:ASPI-1306S
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:150 µH
- Tolerance:±20%
- Current Rating (Amps):1.3 A
- Current - Saturation (Isat):2.1A
- Shielding:Shielded
- DC Resistance (DCR):293mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:2.1MHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.730" L x 0.600" W (18.54mm x 15.24mm)
- Height - Seated (Max):0.300" (7.62mm)
