SPM5020T-4R7M
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 4.7UH 3.4A 74 MOHM SMD
- CategoryFixed Inductors
- Datasheet SPM5020T-4R7M Datasheet
-
ECAD Model
- Share
In Stock: 613
Can ship immediately
Pricing:
- 1$1.65
- 500$0.84636
- 1,000$0.75232
- 2,500$0.72881
- 5,000$0.7053
- 12,500$0.68179
Quote It
Technical Details
- Series:SPM
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Not For New Designs
- Type:Wirewound
- Material - Core:Metal
- Inductance:4.7 µH
- Tolerance:±20%
- Current Rating (Amps):3.4 A
- Current - Saturation (Isat):4.1A
- Shielding:Shielded
- DC Resistance (DCR):74mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.213" L x 0.201" W (5.40mm x 5.10mm)
- Height - Seated (Max):0.079" (2.00mm)
