B82476B1102M100
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1UH 7.5A 8 MOHM SMD
- CategoryFixed Inductors
- Datasheet B82476B1102M100 Datasheet
-
ECAD Model
- Share
In Stock: 889
Can ship immediately
Pricing:
- 1$1.88
- 750$0.92143
- 1,500$0.86722
- 3,750$0.84012
- 5,250$0.81302
Quote It
Technical Details
- Series:B82476B1
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:1 µH
- Tolerance:±20%
- Current Rating (Amps):7.5 A
- Current - Saturation (Isat):9A
- Shielding:Unshielded
- DC Resistance (DCR):8mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.510" L x 0.370" W (12.95mm x 9.40mm)
- Height - Seated (Max):0.200" (5.08mm)
