SRP1270-100M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 10UH 10A 16.8 MOHM SMD
- CategoryFixed Inductors
- Datasheet SRP1270-100M Datasheet
-
ECAD Model
- Share
In Stock: 1,556
Can ship immediately
Pricing:
- 1$1.73
- 400$0.80325
- 800$0.65025
- 1,200$0.612
- 2,800$0.5985
Quote It
Technical Details
- Series:SRP1270
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Iron
- Inductance:10 µH
- Tolerance:±20%
- Current Rating (Amps):10 A
- Current - Saturation (Isat):16A
- Shielding:Shielded
- DC Resistance (DCR):16.8mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:10MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.539" L x 0.539" W (13.70mm x 13.70mm)
- Height - Seated (Max):0.276" (7.00mm)
