744071101
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 100UH 1A 320 MOHM SMD
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 248
Can ship immediately
Pricing:
- 1$2.01
- 300$1.532
Quote It
Technical Details
- Series:WE-TPC
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:100 µH
- Tolerance:±30%
- Current Rating (Amps):1 A
- Current - Saturation (Isat):900mA
- Shielding:Shielded
- DC Resistance (DCR):320mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:6MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.315" L x 0.315" W (8.00mm x 8.00mm)
- Height - Seated (Max):0.181" (4.60mm)
