DFEH10040D-6R8M=P3
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 6.8UH 6.4A 23 MOHM
- CategoryFixed Inductors
- Datasheet DFEH10040D-6R8M=P3 Datasheet
-
ECAD Model
- Share
In Stock: 299
Can ship immediately
Pricing:
- 1$2.22
- 500$1.15836
- 1,000$1.05615
- 2,500$1.02208
- 5,000$0.98801
Quote It
Technical Details
- Series:DFEH10040D
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Not For New Designs
- Type:-
- Material - Core:Iron Powder
- Inductance:6.8 µH
- Tolerance:±20%
- Current Rating (Amps):6.4 A
- Current - Saturation (Isat):8.6A
- Shielding:Shielded
- DC Resistance (DCR):23mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 155°C
- Inductance Frequency - Test:100 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.429" L x 0.394" W (10.90mm x 10.00mm)
- Height - Seated (Max):0.157" (4.00mm)
