744775380
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 8MH 140MA 25 OHM SMD
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 387
Can ship immediately
Pricing:
- 1$2.11
- 500$1.469
Quote It
Technical Details
- Series:WE-ASI
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:8 mH
- Tolerance:±10%
- Current Rating (Amps):140 mA
- Current - Saturation (Isat):90mA
- Shielding:Unshielded
- DC Resistance (DCR):25Ohm Max
- Q @ Freq:-
- Frequency - Self Resonant:700kHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.315" L x 0.276" W (8.00mm x 7.00mm)
- Height - Seated (Max):0.217" (5.50mm)
