B82477P4154M000

Technical Details

• Series:B82477P4
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:150 µH
• Tolerance:±20%
• Current Rating (Amps):1.61 A
• Current - Saturation (Isat):1.7A
• Shielding:Shielded
• DC Resistance (DCR):185mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:-
• Ratings:AEC-Q200
• Operating Temperature:-55°C ~ 150°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.492" L x 0.492" W (12.50mm x 12.50mm)
• Height - Seated (Max):0.335" (8.50mm)
