B82464P4474M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 470UH 500MA 930 MOHM
- CategoryFixed Inductors
- Datasheet B82464P4474M000 Datasheet
-
ECAD Model
- Share
In Stock: 551
Can ship immediately
Pricing:
- 1$2.38
- 750$1.50653
- 1,500$1.45944
- 3,750$1.41237
- 5,250$1.36529
Quote It
Technical Details
- Series:B82464P4
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:470 µH
- Tolerance:±20%
- Current Rating (Amps):500 mA
- Current - Saturation (Isat):550mA
- Shielding:Shielded
- DC Resistance (DCR):930mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.409" L x 0.409" W (10.40mm x 10.40mm)
- Height - Seated (Max):0.189" (4.80mm)
