28225C
Murata Power Solutions
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2MH 350MA 3.72 OHM
- CategoryFixed Inductors
- Datasheet 28225C Datasheet
-
ECAD Model
- Share
In Stock: 457
Can ship immediately
Pricing:
- 1$2.21
- 350$0.94
Quote It
Technical Details
- Series:2800
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:-
- Inductance:2.2 mH
- Tolerance:-
- Current Rating (Amps):350 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):3.72Ohm Max
- Q @ Freq:15.8 @ 800kHz
- Frequency - Self Resonant:3.3MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:10 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.728" L x 0.598" W (18.50mm x 15.20mm)
- Height - Seated (Max):0.299" (7.60mm)
