7447789212
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 120UH 600MA 890 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 430
Can ship immediately
Pricing:
- 1$2.36
- 1,000$1.552
Quote It
Technical Details
- Series:WE-PD Robust
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:120 µH
- Tolerance:±20%
- Current Rating (Amps):600 mA
- Current - Saturation (Isat):680mA
- Shielding:Shielded
- DC Resistance (DCR):890mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:8.5MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.287" L x 0.287" W (7.30mm x 7.30mm)
- Height - Seated (Max):0.138" (3.50mm)
