DRA127-150-R
PowerStor (Eaton)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 15UH 4.83A 27 MOHM SMD
- CategoryFixed Inductors
- Datasheet DRA127-150-R Datasheet
-
ECAD Model
- Share
In Stock: 488
Can ship immediately
Pricing:
- 1$2.81
- 350$1.24913
- 700$1.17973
- 1,050$1.07564
- 3,500$1.04094
- 8,750$1.00624
Quote It
Technical Details
- Series:DRA
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:15 µH
- Tolerance:±20%
- Current Rating (Amps):4.83 A
- Current - Saturation (Isat):9.03A
- Shielding:Shielded
- DC Resistance (DCR):27mOhm
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 165°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.492" L x 0.492" W (12.50mm x 12.50mm)
- Height - Seated (Max):0.315" (8.00mm)
