784770101
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 100UH 2.1A 144 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 276
Can ship immediately
Pricing:
- 1$2.64
- 500$1.88454
Quote It
Technical Details
- Series:WE-PDA
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Nickel Zinc Ferrite (NiZn)
- Inductance:100 µH
- Tolerance:±20%
- Current Rating (Amps):2.1 A
- Current - Saturation (Isat):2.3A
- Shielding:Shielded
- DC Resistance (DCR):144mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:5.2MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:1280
- Size / Dimension:0.472" L x 0.472" W (12.00mm x 12.00mm)
- Height - Seated (Max):0.327" (8.30mm)
