IHLD4032KBER100M5A
Vishay / Dale
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 10UH 5.6A 32.6 MOHM
- CategoryFixed Inductors
- Datasheet IHLD4032KBER100M5A Datasheet
-
ECAD Model
- Share
In Stock: 259
Can ship immediately
Pricing:
- 1$3.23
- 250$1.938
- 500$1.83033
- 750$1.72267
- 1,250$1.66883
- 2,500$1.615
- 6,250$1.56117
Quote It
Technical Details
- Series:IHLD-5A
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:-
- Material - Core:-
- Inductance:10 µH
- Tolerance:±20%
- Current Rating (Amps):5.6 A
- Current - Saturation (Isat):7.4A
- Shielding:Shielded
- DC Resistance (DCR):32.6mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:10.2MHz
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 155°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.384" L x 0.379" W (9.75mm x 9.63mm)
- Height - Seated (Max):0.365" (9.27mm)
