DLH-22-0008
Schurter
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 20UH 7A 12 MOHM TH
- CategoryFixed Inductors
- Datasheet DLH-22-0008 Datasheet
-
ECAD Model
- Share
In Stock: 158
Can ship immediately
Pricing:
- 1$3.3
- 50$3.3
Quote It
Technical Details
- Series:DLH
- Package:Bulk
- Part Status:Active
- Type:-
- Material - Core:-
- Inductance:20 µH
- Tolerance:±15%
- Current Rating (Amps):7 A
- Current - Saturation (Isat):-
- Shielding:Shielded
- DC Resistance (DCR):12mOhm
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:-
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Horizontal - Corner Terminals
- Supplier Device Package:-
- Size / Dimension:0.906" L x 0.512" W (23.00mm x 13.00mm)
- Height - Seated (Max):0.945" (24.00mm)
