SPD74R-563M
API Delevan
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 56UH 1.1A 350 MOHM SMD
- CategoryFixed Inductors
- Datasheet SPD74R-563M Datasheet
-
ECAD Model
- Share
In Stock: 344
Can ship immediately
Pricing:
- 1$3.58
- 1,000$2.89887
- 3,000$2.80536
- 5,000$2.71185
Quote It
Technical Details
- Series:SPD74R
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:56 µH
- Tolerance:±20%
- Current Rating (Amps):1.1 A
- Current - Saturation (Isat):1.1A
- Shielding:Shielded
- DC Resistance (DCR):350mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.287" L x 0.287" W (7.30mm x 7.30mm)
- Height - Seated (Max):0.185" (4.70mm)
